Leo Switched LED (Cord Set)
Polished Chrome 1295027
spec overview
Lamp Included 4.3W LED 134LM 2700K Dry RatedMade to Order
To maintain this product to its best condition, please view our care and cleaning guide.
This product is supplied with a cord and plug for headboard mounting (minimum order quantities apply). Please contact our sales team for more information.
All Astro reading lights are fully adjustable but careful consideration of placement when installing our fixtures can help further optimise reading comfort when in use. Download our positioning guide to learn more.
Specification
| Lamp Required: | No |
|---|---|
| Lumen Output (LM): | 134 |
| Color Temperature (K): | 2700 |
| CRI: | 90 |
| Beam Angle (°): | 16.9 |
| Max Lamp Type & Wattage: | 4.3W LED |
| Switched: | Yes |
| Dimmable: | No |
| Driver Required: | No |
| Certification / Class: | cULus (Class 1) |
| Power Connection Type: | Cord Set |
| Location Rating: | Dry |
| Fitting Method: | Direct to Headboard |
| ADA Compliant: | Yes - if installed in compliance with ADA 307.2, 308, 309.3, 309.4 |
| IC Rated: | Yes |
| Installation Orientation: | Headboard Mount |
| Recess Depth (in): | 1.77 |
| Cutout Shape: | Square |
| Cutout Length (in): | 4.33 |
| Cutout Width (in): | 1.38 |
Downloads
More in the Collection
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1295011 |
|
4.3W LED | 2700K | 90 | 134 | Dry | Wired In | - | - | - | 16.9 | - | - | |
| 1295010 |
|
4.3W LED | 2700K | 90 | 134 | Dry | Wired In | - | - | - | 16.9 | - | - | |
| 1295031 |
|
4.3W LED | 2700K | 90 | 134 | Dry | Cord Set | - | - | - | 16.9 | - | ||
| 1295029 |
|
4.3W LED | 2700K | 90 | 134 | Dry | Cord Set | - | - | - | 16.9 | - | ||
| 1295032 |
|
4.3W LED | 2700K | 90 | 134 | Dry | Cord Set | - | - | - | 16.9 | - | ||
| 1295030 |
|
4.3W LED | 2700K | 90 | 134 | Dry | Cord Set | - | - | - | 16.9 | - | ||
| 1295028 |
|
4.3W LED | 2700K | 90 | 134 | Dry | Cord Set | - | - | - | 16.9 | - | ||
| 1295015 |
|
4.3W LED | 2700K | 90 | 134 | Dry | Wired In | - | - | - | 16.9 | - | - | |
| 1295014 |
|
4.3W LED | 2700K | 90 | 134 | Dry | Wired In | - | - | - | 16.9 | - | - |
You may also like
Configure your Leo
Finish: Polished Chrome
Switched
Choose if your product needs to have a switch or will be controlled remotely.
Power Connection Type
Choose the method of connecting this product to a power source.
Configure to select a product
Made to order
