io 420 3000K Phase
Matt Black 1409026
With its fluted glass shade reminiscent of classical Greek columns, io adds a luxurious allure and comfortable task lighting to any contemporary bathroom. Its damp-rated design and integrated LED lamp make it a safe, energy-efficient lighting choice for installation above or beside the bathroom mirror.
spec overview
Lamp Included 8W LED Damp RatedMade to Order
To maintain this product to its best condition, please view our care and cleaning guide.
Specification
| Lamp Required: | No |
|---|---|
| Lumen Output (LM): | 498 |
| Color Temperature (K): | 3000 |
| CRI: | 90 |
| Beam Angle (°): | 158.5 |
| Max Lamp Type & Wattage: | 8W LED |
| Switched: | No |
| Type Of Dimmer: | Phase - Leading & Trailing Edge |
| Driver Required: | No |
| Primary Shade Finish: | Clear Glass |
| Certification / Class: | cULus (Class 1) |
| Power Connection Type: | Wired In |
| Location Rating: | Damp |
| Fitting Method: |
Stub Out Mount Included Junction Box |
| ADA Compliant: | Yes - if installed in compliance with ADA 307.2, 308, 309.3, 309.4 |
| Title 24 Compliant: | Yes |
| IC Rated: | Yes |
| Installation Orientation: | Wall Mount |
| Recess Depth (in): | 1.54 |
| Cutout Shape: | Square |
| Cutout Length (in): | 7.13 |
| Cutout Width (in): | 1.38 |
Downloads
More in the Collection
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1409018 |
|
21W LED | 3000K | 80 | 2187 | Dry | Wired In | Phase - Leading & Trailing Edge | - | - | 165.5 | - | - | - |
| 1409016 |
|
21W LED | 3000K | 80 | 2187 | Dry | Wired In | Phase - Leading & Trailing Edge | - | - | 165.5 | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1409032 |
|
8W LED | 2700K | 90 | 470 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 157.1 | - | - | - |
| 1409034 |
|
8W LED | 2700K | 90 | 470 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 157.1 | - | - | - |
| 1409033 |
|
8W LED | 2700K | 90 | 470 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 157.1 | - | - | - |
| 1409014 |
|
6.8W LED | 3000K | 90 | 517 | Damp | Wired In | 0-10V | - | - | 158.7 | - | - | |
| 1409029 |
|
6.6W LED | 2700K | 90 | 471 | Damp | Wired In | 0-10V | - | - | 157.2 | - | - | |
| 1409025 |
|
6.8W LED | 3000K | 90 | 517 | Damp | Wired In | 0-10V | - | - | 158.7 | - | - | |
| 1409028 |
|
8W LED | 3000K | 90 | 498 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 158.5 | - | - | |
| 1409031 |
|
6.6W LED | 2700K | 90 | 471 | Damp | Wired In | 0-10V | - | - | 157.2 | - | - | |
| 1409024 |
|
6.8W LED | 3000K | 90 | 517 | Damp | Wired In | 0-10V | - | - | 158.7 | - | - | |
| 1409027 |
|
8W LED | 3000K | 90 | 498 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 158.5 | - | - | |
| 1409030 |
|
6.6W LED | 2700K | 90 | 471 | Damp | Wired In | 0-10V | - | - | 157.2 | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1409043 |
|
7.4W LED | 2700K | 90 | 605 | Damp | Wired In | Phase & 0-10V | - | - | 161.7 | - | - | - |
| 1409051 |
|
7.4W LED | 2700K | 90 | 605 | Damp | Wired In | Phase & 0-10V | - | - | 161.7 | - | - | - |
| 1409044 |
|
7.4W LED | 2700K | 90 | 605 | Damp | Wired In | Phase & 0-10V | - | - | 161.7 | - | - | - |
| 1409019 |
|
7.4W LED | 3000K | 90 | 653 | Damp | Wired In | Phase & 0-10V | - | - | 162.5 | - | - | |
| 1409037 |
|
9.7W LED | 3000K | 90 | 737 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 162.5 | - | - | |
| 1409040 |
|
8.7W LED | 3000K | 90 | 750 | Damp | Wired In | 0-10V | - | - | 162.4 | - | - | |
| 1409045 |
|
9.6W LED | 2700K | 90 | 699 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 162.1 | - | - | |
| 1409048 |
|
8.7W LED | 2700K | 90 | 712 | Damp | Wired In | 0-10V | - | - | 161.8 | - | - | |
| 1409036 |
|
7.4W LED | 3000K | 90 | 653 | Damp | Wired In | Phase & 0-10V | - | - | 162.5 | - | - | |
| 1409039 |
|
9.7W LED | 3000K | 90 | 737 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 162.5 | - | - | |
| 1409042 |
|
8.7W LED | 3000K | 90 | 750 | Damp | Wired In | 0-10V | - | - | 162.4 | - | - | |
| 1409047 |
|
9.6W LED | 2700K | 90 | 699 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 162.1 | - | - | |
| 1409050 |
|
8.7W LED | 2700K | 90 | 712 | Damp | Wired In | 0-10V | - | - | 161.8 | - | - | |
| 1409015 |
|
7.4W LED | 3000K | 90 | 653 | Damp | Wired In | Phase & 0-10V | - | - | 162.5 | - | - | |
| 1409038 |
|
9.7W LED | 3000K | 90 | 737 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 162.5 | - | - | |
| 1409041 |
|
8.7W LED | 3000K | 90 | 750 | Damp | Wired In | 0-10V | - | - | 162.4 | - | - | |
| 1409046 |
|
9.6W LED | 2700K | 90 | 699 | Damp | Wired In | Phase - Leading & Trailing Edge | - | - | 162.1 | - | - | |
| 1409049 |
|
8.7W LED | 2700K | 90 | 712 | Damp | Wired In | 0-10V | - | - | 161.8 | - | - |
