Specification
Lamp Required: | No |
---|---|
Lumen Output (LM): | 517 |
Color Temperature (K): | 3000 |
CRI: | 90 |
Beam Angle (°): | 158.7 |
Max Lamp Type & Wattage: | 6.8W LED |
Switched: | No |
Dimmable: | Yes |
Type Of Dimmer: | 0-10V |
Driver Required: | No |
Primary Shade Finish: | Clear Glass |
Certification / Class: | cULus (Class 1) |
Power Connection Type: | Wired In |
Location Rating: | Damp |
Fitting Method: |
Stub Out Mount Included Junction Box |
ADA Compliant: | Yes - if installed in compliance with ADA 307.2, 308, 309.3, 309.4 |
Title 24 Compliant: | Yes |
IC Rated: | Yes |
Installation Orientation: | Wall Mount |
Recess Depth (in): | 1.54 |
Cutout Shape: | Square |
Cutout Length (in): | 7.13 |
Cutout Width (in): | 1.38 |
