Micro Recess Unswitched
Matt Nickel 1407013
spec overview
Lamp Included 1 x 2W LED 164LM 2700K Dry RatedMade to order
Order Information
This product is subject to minimum quantity orders.
To maintain this product to its best condition, please view our care and cleaning guide.
To ensure you have the correct amount of fittings per driver, please refer to our driver calculator. Alternatively, for more information on drivers, download our Advanced Guide to LED Lights & Drivers.
All Astro reading lights are fully adjustable but careful consideration of placement when installing our fixtures can help further optimise reading comfort when in use. Download our positioning guide to learn more.
Specification
| Lamp Required: | No |
|---|---|
| Lumen Output (LM): | 164 |
| Color Temperature (K): | 2700 |
| CRI: | 90 |
| Beam Angle (°): | 20.9 |
| Max Lamp Type & Wattage: | 1 x 2W LED |
| Switched: | No |
| Dimmable: | Yes |
| Type Of Dimmer: | Control Gear Dependent |
| Driver Required: | Constant Current 700mA |
| Certification / Class: | cULus (Class 2) |
| Power Connection Type: | Wired In |
| Location Rating: | Dry |
| Fitting Method: |
Recessed in Drywall Wall Recessed in Solid Wall |
| ADA Compliant: | Yes - if installed in compliance with ADA 307.2, 308, 309.3, 309.4 |
| IC Rated: | No |
| Direction Adjustable: | Yes |
| Installation Orientation: | Wall Mount |
| Recess Depth (in): | 0.83 |
| Cutout Shape: | Round |
| Hole Saw Diameter: | 17mm / 11/16in |
Find a compatible driver
We provide an easy-to-use online tool to calculate which LED drivers are compatible with your chosen luminaire. Follow the steps to determine the right driver for you.
More in the Collection
| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1407019 |
|
3.2W LED | 2700K | 90 | 196 | Damp | Wired In | - | - | - | 16.0 | - | ||
| 1407017 |
|
3.2W LED | 2700K | 90 | 196 | Damp | Wired In | - | - | - | 16.0 | - | ||
| 1407020 |
|
3.2W LED | 2700K | 90 | 196 | Damp | Wired In | - | - | - | 16.0 | - | ||
| 1407018 |
|
3.2W LED | 2700K | 90 | 196 | Damp | Wired In | - | - | - | 16.0 | - | ||
| 1407016 |
|
3.2W LED | 2700K | 90 | 196 | Damp | Wired In | - | - | - | 16.0 | - | ||
| 1407027 |
|
3.2W LED | 2700K | 90 | 196 | Damp | Cord Set | - | - | - | 16.0 | |||
| 1407024 |
|
3.2W LED | 2700K | 90 | 196 | Damp | Cord Set | - | - | - | 16.0 | |||
| 1407028 |
|
3.2W LED | 2700K | 90 | 196 | Damp | Cord Set | - | - | - | 16.0 | |||
| 1407026 |
|
3.2W LED | 2700K | 90 | 196 | Damp | Cord Set | - | - | - | 16.0 | |||
| 1407023 |
|
3.2W LED | 2700K | 90 | 196 | Damp | Cord Set | - | - | - | 16.0 | |||
| 1407025 |
 |
3.2W LED | 2700K | 90 | 196 | Damp | Cord Set | - | - | - | 16.0 |
Micro Recess Unswitched
Made to order| Code | Finish | Lamp & Wattage | K | CRI | LM | IP | power connection | type of dimmer |
|
|||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 1407014 |
|
2W LED | 2700K | 90 | 164 | Dry | Wired In | Control Gear Dependent | - | - | 20.9 | - | ||
| 1407012 |
|
2W LED | 2700K | 90 | 164 | Dry | Wired In | Control Gear Dependent | - | - | 20.9 | - | ||
| 1407015 |
|
2W LED | 2700K | 90 | 164 | Dry | Wired In | Control Gear Dependent | - | - | 20.9 | - | ||
| 1407011 |
|
2W LED | 2700K | 90 | 164 | Dry | Wired In | Control Gear Dependent | - | - | 20.9 | - |
