Arran Round LED
Solid Brass 1379008
| Lamp Required: | No |
|---|---|
| Max Lamp Type & Wattage: | 1 x 2W LED |
| Location Rating: | Wet |
This product supersedes 1379004
Product Care and Cleaning Guide
To maintain this product to its best condition, please view our care and cleaning guide.
Warranty Information
This product is not suitable for installation within 5 miles of the coast or in a high salt environment.
Specification
| Lamp Required: | No |
|---|---|
| Lumen Output (LM): | 82.46 |
| Color Temperature (K): | 2700 |
| CRI: | 90 |
| Max Lamp Type & Wattage: | 1 x 2W LED |
| Switched: | No |
| Dimmable: | Yes |
| Type Of Dimmer: | Control Gear Dependent |
| Driver Required: | Constant Current 700mA |
| Certification / Class: | cETLus (Class 2) |
| Power Connection Type: | Wired In |
| Location Rating: | Wet |
| Fitting Method: | Recessed in Solid Wall/ Recessed in Drywall Wall |
| ADA Compliant: | Yes - if installed in compliance with ADA 307.2 |
| Title 24 Compliant: | Yes - Exempt from T24 (Marker light |
| IC Rated: | No |
| Installation Orientation: | Wall Mount |
| Recess Depth: | 83.5 |
| Cutout Shape: | Round |
| Hole Saw Diameter: | 105mm / 4-1/8in |
Downloads
More in the Collection
| Code | Finish | Lamp & Wattage | K | CRI | LM | Location |
|
||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1379007 |
|
2W LED | 2700K | 90 | 66.46 | Wet | - | - | - | - | |
| 1379003 |
|
2W LED | 2700K | 90 | 66.46 | Wet | - | - | - | - |
| Code | Finish | Lamp & Wattage | K | CRI | LM | Location |
|
||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1379004 |
|
2W LED | 2700K | 90 | 82.46 | Wet | - | - | - | - |
